ENGINE
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
DISPLAY
Yamaha, Side Switch, 1.7" LCD, 7 functions
BATTERY
InTube, 630 Wh
FRAME FAMILY
Haibike, Aluminium 6061, Yamaha InTube 630, HD Interface, Aluminium 6061
FORK
SR Suntour, NEX E25-HLO, Lockout, Steel spring, 63 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
CRANK ARM
Haibike, Forged, Aluminium
BRAKE (FRONT)
Alhonga, HT474, Hydraulic disc brakes
BRAKE (REAR)
Alhonga, HT474, Hydraulic disc brakes
TUBE
Dunlop valve
RIM
Schürmann, Yak25, With Eyelets, Double Wall, Aluminium
CLAMPING RING
Quick release, 34.9 mm
REAR DERAILLEUR
Shimano, Deore M4120
|
SHIFT LEVER
Shimano, Deore M4100, Trigger switch
BOTTOM BRACKET
Integrated in the motor
SPROCKET
Shimano, CSM4100, 11 - 42 teeth
CHAIN
KMC, e10S
CHAINRING
Steel, 38 teeth
BRAKE LEVER
Alhonga, HT474, Aluminium
BRAKE DISC (FRONT)
Alhonga, DXR1806, 180 mm
BRAKE DISC (REAR)
Alhonga, DXR1806, 180 mm
TYRE
Schwalbe, Al Grounder Performance, 60-584, 27.5 x 2.4 inch
FRONT WHEEL HUB
Alu hub
REAR WHEEL HUB
Alu Nabe, 6-bolt standard
SPOKES
Sapim, Leader
HANDLEBAR
XLC, Topflat, 720 mm
|
GRIPS
XLC, Comfort bo3
STEM
XLC, Alu, A-head
HEADSET
Feimin, A-Head Tapered, Ball bearing Cane Creek, Viscoset, Aluminium
SADDLE
XLC, Trekking
SEAT POST
XLC, Aluminium, Patent, 31.6 mm
PEDALS
VP, E461, Aluminium, with Reflector
HEADLIGHT
Haibike, Skybeamer 150, 50 lm
REAR LIGHT
AXA, Juno Ebike
DYNAMO
Via system battery
CARRIER
Massload, Systemgepäckträger
FENDERS
Eurofender, Tempo, ChromoplasticsSKS, Chromoplastics
STAND
Ursus, Mooi, Rear stand
PERMITTED TOTAL WEIGHT
130.0 kg
|
